- Includes components for the rail
- Easy DIY installation
- Rail length is 6ft (1830mm)
- Powder-coated for outdoor durability
- Designed in line with BS 6180:2011
Couldn't load pickup availability
This Aluminium Balustrade Railing Kit includes everything you need to install a horizontal rail section between two posts. Each kit comes complete with a powder-coated top rail and bottom rail, pre-sized to fit standard spacing — and fully customisable to suit any project without compromising on structural integrity or appearance. Designed in compliance with British Building Regulations, this kit provides safety, strength, and a sleek modern look.
It includes all necessary brackets and fixings for quick assembly, and is fully compatible with all aluminium balustrade posts and accessories from The Outdoor Look. Whether you're installing on decking, concrete, or balcony surfaces, this railing system delivers reliable, low-maintenance performance.
Suitable for flat or stair applications (when paired with the appropriate brackets), this aluminium rail kit provides a solid foundation for your outdoor balustrade system.
| Specification | Value |
|---|---|
| Material | Aluminium Alloy 6005 |
| Colour | Black (RAL9017) |
| Finish | Powder Coated (Matt) |
| Height | 1100mm |
| Width | 1830mm |
| Weight | 8.4kg |
| Fixing Method | Level Ground |
| Top Rail | 1 |
| Bottom Rail | 1 |
| Vinyl Insert | 2 |
| Spindles | 15 |
| Spindle Spacers | 16 |
| Brackets | 4 |
| 1.25 Screws | 8 |
| 0.75 Screws | 8 |
| Bottom Rail Support | 1 |
Yes — we accept returns of unused items in their original packaging within 30 days.
Please contact us before returning to confirm eligibility and process.
Yes. The system is made from aluminium with a durable powder-coated finish, making it:
It’s designed for year-round outdoor exposure in UK conditions.
Yes. You’ll need to purchase a Stair Bracket Kit, which is sold separately.
This allows the rails to be installed at an angle to follow your stair pitch.
No — posts are sold separately.
The Rail Kit includes:
Stainless steel screws and fixings
Yes. Use a hacksaw or metal-cutting saw.
Cut both ends evenly to ensure symmetrical picket spacing. Always measure carefully and wear protective gear when cutting.
The maximum spacing between posts is 1829mm (72"). This is the longest internal span your aluminium rail is designed to support.
However, you can cut the rails down to fit shorter gaps if needed. Always cut equal amounts from both ends to maintain balanced picket spacing.
Tip: Cut rails approximately 3.5mm shorter than the post-to-post gap to allow for bracket clearance.
The rail kit includes the top and bottom rails (with vinyl inserts), pickets, spacers, top and bottom brackets, a rail support foot, and stainless steel screws and fixings. Posts are sold separately, so you can buy the exact number your layout needs.
The rails come in a standard 1829mm length — this is the only length supplied, and it's designed to span up to the maximum 1829mm post spacing. Rails can be cut down on site to fit shorter gaps between posts.
You'll need one rail kit per bay (the gap between two posts). Our balustrade calculator works out exactly how many rail kits your run needs, along with the posts and other parts, based on your measurements.
