Gate Hinge Assembly – 48.3mm Tube
Key Features
SKU:
WB-GATEHINGE
Availability:
Many In Stock
Subtotal:
£11.00inc VAT
Secure checkout — pay your way
Delivery: £60 to most UK mainland — free on orders over £2,000. Delivered within 2–5 working days;
exact cost confirmed at checkout by postcode.
Full delivery & returns details →
Full delivery & returns details →
316 Marine-Grade Stainless Steel
Built for UK weather, including coastal locations
Couldn't load pickup availability
Description
The gate hinge assembly hangs a tube-framed gate from a 48.3mm post. Both halves cradle round tube, so the hinge clamps to the post on one side and the gate stile on the other with no welding and no drilling of the post. It swings through 90 degrees.
Use two per leaf. There is no ready-made gate in the wire balustrade range — gates are built on site from handrail tube, corner elbows and the same wire and fittings used on the runs, with the stiles drilled at 132mm centres so the wires line through when the gate is shut. Pair with the gate latch assembly.
316 marine-grade stainless steel, matching the rest of the wire balustrade system. Planning a gate? Call the team on 01282 526428 and we'll size it with you.
Specifications
| Specification | Value |
|---|---|
| Material | 316 Marine-Grade Stainless Steel |
| Type | Gate hinge assembly |
| Suits Tube | 48.3mm, both halves |
| Plate Size | 59.7mm x 30mm x 10mm |
| Fixing Holes | 4 x 6.6mm countersunk, at 40mm centres |
| Swing | 90 degrees |
| Weight | 0.03kg |
| Quantity | Two per gate leaf |
| Finish | Satin |
Useful Documents
-
TOL WIRE BAL Technical Specification
-
TOL WIRE BAL Warranty Maintenance
-
TOL WIRE BAL Troubleshooting
