Gate Latch Assembly – 48.3mm Tube
Key Features
SKU:
WB-GATELATCH
Availability:
Many In Stock
Subtotal:
£11.90inc VAT
Secure checkout — pay your way
Delivery: £60 to most UK mainland — free on orders over £2,000. Delivered within 2–5 working days;
exact cost confirmed at checkout by postcode.
Full delivery & returns details →
Full delivery & returns details →
316 Marine-Grade Stainless Steel
Built for UK weather, including coastal locations
Couldn't load pickup availability
Description
The gate latch assembly holds a tube-framed gate shut. Both halves cradle round tube, clamping to the 48.3mm gate stile and the closing post or second leaf with no welding. The catch adjusts across a 15–35mm gap, so it takes up the tolerance you actually end up with on site rather than the one on the drawing.
One per gate. Pair with two gate hinge assemblies per leaf. On a double gate — two leaves meeting in the middle of a wider opening — you'll also need a drop bolt at ground level to hold the closing leaf while the latch does its job. That isn't part of this system and needs sourcing separately.
316 marine-grade stainless steel, matching the rest of the wire balustrade system. Planning a gate? Call the team on 01282 526428 and we'll size it with you.
Specifications
| Specification | Value |
|---|---|
| Material | 316 Marine-Grade Stainless Steel |
| Type | Gate latch assembly |
| Suits Tube | 48.3mm, both halves |
| Plate Size | 59.7mm x 30mm x 10mm |
| Fixing Holes | 4 x 6.6mm countersunk |
| Overall Length | 95mm |
| Gap Adjustment | 15mm to 35mm |
| Weight | 0.05kg |
| Quantity | One per gate |
| Finish | Satin |
Useful Documents
-
TOL WIRE BAL Technical Specification
-
TOL WIRE BAL Warranty Maintenance
-
TOL WIRE BAL Troubleshooting
